Shenzhen Zhongtu Automation Technology Co., Ltd.
1 Years
| Ask Lasest Price | |
| Brand Name : | ZT |
| Model Number : | ZT-DJ331-01 |
| Certification : | CE |
| Price : | USD1400-1600/SET |
| Payment Terms : | T/T |
| Supply Ability : | 100SET/Month |
| Delivery Time : | 15-30Day |
Desktop Single-head Single-platform Automatic Dispensing Machine
Product description:
Automatic dispensing machine features:
1, Automatic dispensing machine greatly improves the product gluing
quality and production efficiency. Due to the application of
automatic control technology, it can accurately control the time,
position, speed and mode of gluing, avoid the error caused by
manual control, thus greatly improving the accuracy and stability
of gluing, and can save a lot of manpower, save time, and improve
production efficiency.
2, The use of automatic dispensing machine has caused more market
demand. Due to the current mass production of electronic products
on the market need dispensing treatment, such as LED packages,
mobile phone keyboards, connectors, etc., automatic dispensing
machine plays an increasingly important role in this regard,
causing the market for automatic dispensing machine growing demand.
3, The maintainability of the automatic dispensing machine is very
high, easy to operate, easy to maintain and maintain. The
mechanical operation part and control system of the automatic
dispensing machine are designed and configured by engineers and
circuit professionals, which can ensure the accuracy of the
indicators, and the maintenance of the equipment itself is
relatively easy, repair and maintenance are simple operations, and
the replacement and cleaning of the various parts of the machine
are also very easy to carry out.
Product parameter:Name: | Glue Dispensing Machine | Place of Origin: | ShenZhen,China | |
Applicable Industries: | Manufacturing Plant | Key Selling Points: | Automatic | |
Video outgoing-inspection: | Provided | Weight (KG): | 60Kg | |
Marketing Type: | New Product 2024 | Voltage: | 110~230V 50~60Hz | |
Warranty period: | 1 Year | Dimensions: | 800*750*850mm | |
Warranty of core components: | 3 Years | Applicable glue | All kinds of industrial glue | |
Core Components: | PLC | Repeate Accuracy: | ±0.02mm | |
Power: | 650W | Heating temperature: | 0~200ºC | |
Electric current: | 5A | Working Air Pressure: | 0.4~0.6Mpa | |
Model | ZT-DJ331-01 | ZT-DJ441-02 | ZT-DJ411-B02 | ZT-SDDJ310 | Fixture Customization |
Dispensing Speed: | According to customer's product requirements and glue types | Need | |||
Working Air Pressure: | 0.4~0.6Mpa | Editorial Model: | Manual/Automatic | ||
Maximum Load Weight: | 8kgs (for work platform) | Transmission mode: | Precision Stepping Motor+Timing belt | ||
Machine Axis Number | 3 axis | 4 axis | 4 axis | 4 axis | Max moving speed |
X Axis | 400mm | 400mm | 400mm | 400mm/2X | 0~600mm/s |
Y Axis | 300mm | 300mm/2Y | 300mm/2Y | 300mm/2Y | 0~600mm/s |
Z Axis | 100mm | 100mm | 100mm | 100mm | 0~400mm/s |
Operating instructions | Single-machine operation,simple installation,easy program
setup,strong PC compatibility,and logo shop software,can import CAD
file settings. | ||||
Teaching Method | Remote Teaching/Manual Data Input/Optional:LCD Touch Screen | ||||
Teaching File Capacity | Up to 999 files,single file up to 1000 points | ||||
Weight(Kg) | 50Kg | 65Kg | 65Kg | 85Kg | Customized |
Size(mm) | 600*750*850 | 800*750*850 | 850*750*850 | 1000*750*850 | To order |
Pre-Sale | In Sale | After Sale |
1.Product Introduction, 2.Technical Communication, 3.Remote consulting service | 1. Show the product, 2. Explain in detail how to use the product , 3. Answer the questions raised by customers. | 1.Support video service 2.The whole equipment is guaranteed for 1 year; 3.The guide rail/motor/control parts is guaranteed for 3 years. |
1. who are we?
We are based in Guangdong, China, start from 2015, There are total
about 50-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final
Inspection before shipment;
3.what can you buy from us?
Soldering machine,Precision spot welding machine,Glue
dispenser,Screw machine
4. why should you buy from us not from other suppliers?
With ultra professional service and skill to provide high
performance but competitive price goods, the customer's success is
our own success.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,FCA,CPT; Accepted Payment
Currency:USD,EUR,HKD,CNY; Accepted Payment Type: T/T,PayPal,Cash;
6.What is your Warranty for the product? How do you carry out it?
We provide 1 Year Warranty for unit machine and 3 years warranty
for main board.More details pls contact me.
7. May I buy samples from you?
Yes! You are welcome to place sample order to test our superior
quality and service.
8.Are you just trading company or factory?
We are professional manufacturer for automation machine since 2015.
|
|
